RF beauty device with Ultrasonic function

RF Beauty Device

What is RF Beauty Device?

A RF beauty device is a device that uses radio frequencies to improve the appearance of skin. RF beauty devices can help to improve the appearance of wrinkles, fine lines, and uneven skin tone. Here we’ll introduce our case about RF beauty device.

Case of RF Beauty Device

RF Beauty Device facial wrinkle removal

RF Beauty Device - Medical Use

Wroking principle: High intensity focus ultrasoud
Wrinkle heads:1.5mm,2.0mm,3.0mm,4.5mm,6mm,9.0mm,13mm
Energy type: 4Mhz/7Mhz
Shot length: 25mm
Shot lines: 1line
Shots for face: 20,000 shots/each
Shots for body: 30,000 shots/each
Voltage: 110v-220v
Heat temperature: 40 - 60 degree
Warranty: One years
Certificate: Medical CE certificate

Application

– improve skin tone and elasticity;
– reduce the appearance of fine lines and wrinkles;
– diminish the appearance of age spots;
– promote collagen production;
– improving circulation;
– Reduces the appearance of wrinkles and fine lines;
– Stimulates collagen production;
– Increases blood circulation;
– Promotes lymphatic drainage;
– Reduces the appearance of cellulite.

Feature Introduction

It can achieve the dual functions of ultrasonic scalpel and Thermage.

This instrument has 7 kinds of consumable probes, which can perform multiple lifting and anti-aging, and the effect is remarkable. The probe of this product uses MMFU technology.

The energy generated by the 4-7MHZ transducer can form micro-coagulation in the dermis and fascia layers, while the 2MHZ transducer transmits macroscopic energy to the subcutaneous fat layer, selectively reducing fat cells.

This product has very good effects on improving tiger lines, forehead lines, lifting eyebrows and apple muscles, tightening double chin, fine pores, even and whitening skin texture, eye beauty, shaping and enhancing body firmness.

Our company can provide analysis and development of consumables for this product. If you have any needs, welcome to consult.

Schematic and Layout

RF beauty device layout
RF beauty device layout
RF Beauty Device Schematic
RF beauty device schematic

How does RF beauty device work?

RF beauty device uses radio frequency waves to heat up the dermis layer of the skin. This action causes the collagen fibers in the skin to contract and produce new collagen. The result is firmer, smoother, and younger-looking skin.

human skin structure
visible change

Internationally, radio frequency beauty equipment operate at 1MHz to 6MHz. The 4MHz frequency is suitable for minimally invasive tissue and blood vessel cutting. Medical applications operate in the 1MHz to 6MHz frequency range. A lower frequency (typically 0.5 to 1.0MHz) is used for safety, as it is for beauty equipment. The higher the frequency, the higher the degree of control required for the instrument, the operator’s skill, and other elements. Although home radio frequency beauty equipment has a lower energy level than medical treatment, it requires a longer cycle, it is still effective if used correctly.

human skin structure 2
human skin structure

The radio frequency beauty device does not guarantee the same results for everyone. Rather, the device results vary from person to person and from instrument to instrument, because the device’s effectiveness is dependent on a variety of factors, including the dermis layer’s maximum temperature, radio frequency duration, skin moisture content, and age.

Gel for radio frequency beauty Device

The gel helps to prevent burns by guiding radio frequency energy to the deep layer, avoiding the creation of the shortest electric field lines between the electrodes. The positive and negative electrodes will locate the shortest ‘work-saving’ path when the device is on, which is a direct line between two points.

On the other hand, the electric field lines are guided near the skin surface so that they avoid the creation of excessive energy while simultaneously guiding the electric field lines to the deep layer. By avoiding the creation of excessive energy and epidermal burns while guiding the energy to the deep layer, the radio frequency beauty device minimizes the loss of RF energy during transmission, and provides the proper nursing effect.

gel for radio frequency beauty Device
gel for radio frequency beauty Device

When heated by radio frequency, the gel forms a thermal insulation layer and a protective film on the skin surface, maintaining the dermis temperature as stable and enduring as possible. Maintaining a stable and enduring thermal environment in the dermis is one of the necessary conditions for producing the collagen regeneration results of radiofrequency technology.
